U-Board KS-TG919 (ver. 1.0)
chipChipset
cpuSocket
Socket 3 (PGA237)
speedFSB speeds
25MHz33MHz40MHz50MHz
moboForm factor
Baby AT (max 220 x 330 mm)
dimDimensions
220mm x 260mm
chipCache
64KB128KB256KB512KB1MB
ramMax RAM size
64MB
ramRAM types
30-pin SIMM72-pin FPM
pwrPSU connector
AT (P8-P9)
connI/O ports
1x
AT Keyboard
cardExpansion slots
7x
16-bit ISA
3x
32-bit VLB

Notes:

User "Peter" reports:

  • The Level 2 cache is detected and shown on the boot screen, but otherwise disabled. Bios settings do not affect the cache which remains permanently disabled
  • Memory timing settings in the bios have no effect. The memory remains permanently at slower settings

The user reports that an alternative to use may be the BIOS for the Mitac/Trigon IH4077D: https://theretroweb.com/motherboards/s/mitac-trigon-ih4077d-rev-d1

Last updated 2024-01-03T20:24:12Z
Board info score is 9.4/10
1 file available

Vendor: Award [2 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
08/03/94-EFAR-EC802G-B-2C403U01-0B
Note
Core version
BIOS version
Logs
POST string
02/23/95-EFAR-EC802G-B-2C4O3U0Z-00
Note
Core version
4.50G
BIOS version
Logs
drv No drivers available
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1995
File
Logs
Family
Release date
File
Logs
Family
Release date
1989-04
File
Logs
Family
Release date
1990
File
Logs
Family
Release date
1992-10
File
Logs
Family
Release date
1992-02
File
Logs
