Shuttle HOT-419 (VER. R1.1)
chipChipset
cpuSocket
Socket 3 (PGA237)
speedFSB speeds
20MHz25MHz33MHz40MHz50MHz
moboForm factor
Baby AT (max 220 x 330 mm)
dimDimensions
260mm x 220mm
chipCache
64KB128KB256KB512KB
ramMax RAM size
128MB
ramRAM type
72-pin FPM
pwrPSU connector
AT (P8-P9)
connI/O ports
1x
AT Keyboard
cardExpansion slots
6x
16-bit ISA
3x
32-bit VLB
2x
8-bit ISA

Also known as:

Notes:

This board supports 3v, 3.3v, 3.45v, and 5v CPU voltages.

WARNING: The MTL Jumper Manual has a misprint:

For 256K Cache, JP13 must be set to 2-3, as printed on the silkscreen of the motherboard.

Last updated 2024-02-22T14:16:24Z
Board info score is 9.1/10
chipChipset parts
OPTi 82C895 OPTi 82C601/602
cpuCPU family support
1 file available

Vendor: AMI [2 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
40-0001-001343-00101111-101094-OP802GA
Note
Core version
101094
BIOS version
Logs
POST string
40-0102-001343-00101111-072594-OPTI802-U
Note
Core version
072594
BIOS version
Logs
