PCChips/Hsin Tech M596
Logs
chipChipset
cpuSocket
Socket 7 (PGA321)
speedFSB speeds
50MHz55MHz60MHz66MHz75MHz
moboForm factor
MicroATX (max 244 x 244 mm)
dimDimensions
244mm x 190mm
ramMax VRAM size
4MB
chipCache
512KB
ramMax RAM size
512MB
ramRAM types
SDR UDIMM168-pin EDO UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
maxcpuMulti CPU support
no
tag Also known as
connI/O ports
1x
3.5mm Audio Combo
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
2x
USB 1.x
1x
VGA
cardExpansion slots
1x
16-bit ISA
3x
32-bit PCI
Last updated 2025-02-20T14:37:39Z
Board info score is 9.4/10
bios 4 BIOS files available

vendor AMI - 4 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
51-0323-001437-00101111-071595-SIS5598-007_66_S596
Note
Core version
071595
BIOS version
Logs
POST string
51-0205-001437-00101111-071595-SIS5598-007_66_S596
Note
Core version
071595
BIOS version
Logs
POST string
51-0706-001437-00101111-071595-SIS5598-007_66_S596
Note
PCB 1.3
Core version
071595
BIOS version
Logs
POST string
51-0503-001437-00101111-071595-SIS5598-007_66_S596
Note
PCB 1.3
Core version
071595
BIOS version
Logs
drv 8 drivers available
Name
Version
OS support
Size
Filename
Name
Version
4.10.0.00152
OS support
Windows 9x Windows NT 4.0
Size
35.9MB
Filename
Name
Version
4.10.00.0152
OS support
MS-DOS Windows 3.1x Windows 9x Windows NT 4.0
Size
27.2MB
Filename
Name
Version
4.10.00.0200
OS support
Windows 9x
Size
3.7MB
Filename
Name
Version
4.10.00.0164
OS support
Windows 9x
Size
3.7MB
Filename
Name
Version
4.10.00.0130
OS support
Empty
Size
863.1KB
Filename
Name
Version
1.13
OS support
Windows 2000 Windows 9x Windows NT 3.5x Windows NT 4.0
Size
Empty
Filename
Name
Version
2.04A
OS support
Windows 2000 Windows 9x Windows XP
Size
Empty
Filename
Name
Version
2.13
OS support
MS-DOS OS/2 Warp 3.x OS/2 Warp 4.x Windows 9x Windows NT 3.1 Windows NT 3.5x Windows NT 4.0
Size
Empty
Filename
doc 4 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
2000-09
File
Logs
Family
Release date
1999-12
File
Logs
Family
Release date
2000-04
File
Logs
Family
Release date
2000-11
File
Logs
Family
Release date
1997-06
File
Logs
Family
Release date
1998-01
File
Logs
Family
Release date
1997-06
File
Logs
Family
Release date
1997-08
File
Logs
image1 Image 1 of 2 (Microhouse)
image2 Image 2 of 2

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
