Octek HIPPO 10 486
chipChipset
cpuSocket
Socket 3 (PGA237)
speedFSB speeds
20MHz25MHz33MHz40MHz50MHz
moboForm factor
Baby AT (max 220 x 330 mm)
dimDimensions
254mm x 218mm
chipCache
128KB256KB512KB
ramMax RAM size
64MB
ramRAM type
72-pin FPM
pwrPSU connector
AT (P8-P9)
connI/O ports
1x
AT Keyboard
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
Parallel
2x
Serial
cardExpansion slots
6x
16-bit ISA
2x
32-bit VLB

Known issues:

  • Leaky Ni-Cd clock battery

The Ni-Cd battery may be leaking, risking damage to PCB layers & nearby components. Promptly remove the battery & clean corrosion/alkaline salts from the board. Use white vinegar to dissolve salts, but exercise caution as vinegar can corrode exposed metals. A thorough examination & repair may be needed. Replace battery with guide: https://github.com/wiretap-retro/Not-A-Varta

Last updated 2024-02-27T11:29:55Z
Board info score is 9.4/10
chipChipset parts
UMC UM8496 UMC UM8498F
chipSuper I/O chips
UMC UM82C863F
chipIDE ctrl. chips
UMC UM8672F (VLB IDE Controller)
cpuCPU family support
3 files available

Vendor: Award [3 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
11/28/95-UMC-498GP-2C4X6O01-00
Note
Core version
4.50G
BIOS version
Logs
POST string
01/09/96-UMC-498GP-2C4X6O01-00
Note
Core version
4.50G
BIOS version
Logs
POST string
12/14/94-UMC-498GP-2C4X6O01-00
Note
Core version
4.50G
BIOS version
Logs
drv 1 driver available
Name
Version
OS support
Size
Filename
Name
Version
2.1
OS support
MS-DOS OS/2 2.x Windows 3.1x Windows NT 3.1
Size
990.1KB
Filename
doc 2 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
1989-04
File
Logs
Family
Release date
1990
File
Logs
Family
Release date
1992-10
File
Logs
Family
Release date
1992-02
File
Logs
