MSI MS-6380E U
Logs
Chipset
Socket
FSB speeds 200 MHz266 MHz
Form factorATX (max 305 x 244 mm)
Dimensions305mm x 235mm
Cache
None/Integrated in the CPU
Max RAM size
3 GB
RAM type DDR UDIMM
PSU connector
Also known as
- MSI KT3 Ultra-ARU
I/O ports1x
Floppy interface
1x
Gameport
4x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
S/PDIF
2x
Serial
4x
USB 1.x
4x
USB 2.0
Expansion slots5x
32-bit PCI
1x
CNR
1x
Universal AGP
Notes
Uses PDC20276 RAID controller.
Uses NEC D720100AS1 USB 2.0 controller.
Last updated 2024-02-24T23:27:14Z
Board info score is 9.4/10
Chips
-> Chipset part
-> Audio
-> Clock Synth / PLL
CPU family support
7 BIOS files available
AMI - 7 entries
POST string
Note
Core Ver.
BIOS Ver.
Logs
5 drivers available
Name
Version
Arch
OS support
Size
Filename
Name
Version
A4.06
Arch
x86
OS support
Windows 2000
Windows XP/2k3
Size
17.9MB
Filename
Name
Version
5.70d
Arch
x86
OS support
Windows 2000
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Windows XP/2k3
Size
3.9MB
Filename
Name
Version
V3.00a
Arch
x86
OS support
MS-DOS
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP/2k3
Size
1.9MB
Filename
Version
Arch
OS support
Size
Filename
Version
Arch
OS support
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP/2k3
Size
1.1MB
Filename
Version
Arch
OS support
Windows 2000
Windows 9x
Windows XP/2k3
Size
973.7KB
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Image 1 of 2 (evasive)
Image 2 of 2
