Leadtek WinFast K7NCR18D PRO
Chipset
Socket
FSB speeds 200MHz266MHz333MHz400MHz
Form factorATX (max 305 x 244 mm)
Dimensions304.8 x 243.8 mm
Cache
None/Integrated in the CPU
Max RAM size
3GB(DDR400)
RAM type DDR UDIMM
PSU connector
I/O ports1x
3.5mm Audio Combo
1x
Floppy interface
2x
IDE interface
1x
IrDA
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
1x
S/PDIF
1x
Serial
6x
USB 2.0
Expansion slots1x
1.5V AGP
4x
32-bit PCI
1x
ACR
Known issues:
- Faulty or Leaking Electrolytic Capacitors
Some motherboards may contain faulty or leaking electrolytic capacitors, which can negatively impact system performance or stability. These capacitors may exhibit issues such as bulging, leaking, or even exploding, potentially damaging other components on the motherboard. Users should inspect their capacitors regularly and replace any that are faulty or leaking to avoid damage or system instability.
Notes:
LDO6 gets extremely hot and is a common failure point. It is located at the bottom left of the RAM slots.
Last updated 2023-10-01T13:56:07Z
Board info score is 9.6/10
Chipset partsAudio chipsSuper I/O chips
CPU family support
3 files available
Vendor: Award [3 entries]
POST string
Note
Core Ver.
BIOS Ver.
Logs
1 known good driver available
Name
Version
OS support
Size
Filename
Name
Version
4.27
OS support
Windows 9x
Size
6.9MB
Filename
Name
Version
OS support
Size
Filename
Name
Version
A4.06
OS support
Windows 2000
Windows 9x
Windows XP
Size
17.9MB
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Image 1 of 3 (Eric Voirin (oerg866))
Image 2 of 3 (Eric Voirin (oerg866))
Image 3 of 3 (Eric Voirin (oerg866))
