Intel DZ77GA-70K
chipChipset
cpuSocket
Socket H2 (LGA1155)
speedFSB speed
Empty
moboForm factor
ATX (max 305 x 244 mm)
dimDimensions
305mm x 244mm
chipCache
None/Integrated in the CPU
ramMax RAM size
32GB(DDR3-2400)
ramRAM type
DDR3 UDIMM
pwrPSU connector
12V EPS Connector (8-pin EPS) ATX 2.x (24-pin ATX)
connI/O ports
1x
3.5mm Audio Combo
1x
HDMI
2x
IEEE 1394
1x
IrDA
1x
PS/2 KB+MS Combo
2x
RJ-45 LAN
1x
S/PDIF
4x
SATA II
4x
SATA III
1x
Serial
1x
Toslink
8x
USB 2.0
8x
USB 3.0
1x
eSATA III
cardExpansion slots
2x
32-bit PCI
2x
PCIe x1
1x
PCIe x16
1x
PCIe x16 @ x8
1x
PCIe x4

Notes:

  • supports CrossFire and SLI.
Last updated 2023-07-28T12:26:23Z
Board info score is 9/10
4 files available

Vendor: AMI [4 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
GAZ7711H.86A.0066.2013.0521.1509
Note
Core version
BIOS version
Logs
POST string
GAZ7711H.86A.0064.2013.0313.1822
Note
Core version
BIOS version
Logs
POST string
GAZ7711H.86A.0049.2012.0713.1518
Note
Core version
BIOS version
Logs
POST string
GAZ7711H.86A.0035.2012.0410.2011
Note
Core version
BIOS version
Logs
