HP Vectra VL 5/XXX Series 4 (Chimay)
Logs
chipChipset
cpuSocket
Socket 7 (PGA321)
speedFSB speeds
50 MHz60 MHz66 MHz
moboForm factor
OEM / Proprietary
dimDimensions
254mm x 218mm
ramMax VRAM size
2 MB
chipCache
256KB
ramMax RAM size
128 MB
ramRAM types
72-pin FPM72-pin EDO
pwrPSU connector
OEM/Proprietary
tag Also known as
  • HP D3660-6xxxx
connI/O ports
1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
cardExpansion slots
3x
16-bit ISA
3x
32-bit PCI
notes Notes

Optional S3 Trio64 or S3 Trio64V+ video. Uses propietary form factor similar to NLX.

Last updated 2022-09-26T10:59:09Z
Board info score is 9/10
bios 2 BIOS files available

vendor Phoenix - 2 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
Note
onboard S3 764/765 series
Core version
4.05
BIOS version
Logs
POST string
Note
Core version
4.05
BIOS version
Logs
drv 9 drivers available
Name
Version
Arch
OS support
Size
Filename
Name
Version
3.00
Arch
x86
OS support
OS/2 Warp 3.x Windows NT 3.5x Windows NT 4.0
Size
1.2MB
Filename
Name
Version
2.41.07
Arch
x86
OS support
Windows 9x
Size
183.6KB
Filename
Name
Version
1.70.04
Arch
x86
OS support
Windows 3.1x
Size
606.1KB
Filename
Name
Version
1.6
Arch
x86
OS support
OS/2 1.x OS/2 2.x OS/2 Warp 3.x
Size
1.2MB
Filename
Name
Version
2.01.09
Arch
x86
OS support
Windows 9x
Size
124.2KB
Filename
Name
Version
2.00.18
Arch
x86
OS support
Windows NT 4.0
Size
177.7KB
Filename
Name
Version
3.7B / 3.7D
Arch
x86
OS support
MS-DOS NetWare Server 3 NetWare Server 4 OS/2 Warp 3.x Windows 3.1x Windows 9x Windows NT 3.5x
Size
1.6MB
Filename
Version
Arch
OS support
Size
Filename
Version
Arch
x86
OS support
Windows 9x
Size
577.8KB
Filename
Version
Arch
x86
OS support
Windows 9x
Size
569.7KB
Filename
doc 4 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1996
File
Logs
Chip
Release date
1996
File
Logs
Chip
Release date
1996-02
File
Logs
Chip
Release date
1995-07
File
Logs
image1 Image 1 of 4 (Microhouse)
image2 Image 2 of 4 (Carlos S. M.)
image3 Image 3 of 4 (Carlos S. M.)
image4 Image 4 of 4 (Carlos S. M.)
