Foxconn NF3UK8MA-RS
Logs
chipChipset
cpuSocket
Socket 939 (mPGA939)
speedFSB speeds
800MHz1000MHz
moboForm factor
MicroATX (max 244 x 244 mm)
dimDimensions
Empty
chipCache
None/Integrated in the CPU
ramMax RAM size
2GB
ramRAM type
DDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX) ATX P4 connector 12v (4-pin P4)
connI/O ports
1x
3.5mm Audio Combo
1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
1x
S/PDIF
2x
SATA I
1x
Serial
8x
USB 2.0
cardExpansion slots
1x
1.5V AGP
3x
32-bit PCI
notes Notes

Options:
-L 10/100Mbit LAN
-K Gigabit LAN
-6 6-channel audio
-8 8-channel audio
-E IEEE1394
-S SATA
-R RAID

Last updated 2023-08-15T09:05:42Z
Board info score is 9.5/10
bios 2 BIOS files available

vendor Award - 2 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
07/12/2005-nForce-6A61CLBDC-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
04/08/2005-nForce-6A61CLBDC-00
Note
Core version
6.00PG
BIOS version
Logs
drv 10 drivers available
Name
Version
OS support
Size
Filename
Name
Version
A4.06
OS support
Windows 2000 Windows 9x Windows XP
Size
17.9MB
Filename
Name
Version
5.10
OS support
Windows 2000 Windows XP
Size
30.6MB
Filename
Name
Version
4.27
OS support
Windows 9x
Size
6.9MB
Filename
Name
Version
4.27
OS support
Windows 9x
Size
6.9MB
Filename
Name
Version
1.3
OS support
Windows 9x
Size
19KB
Filename
Name
Version
1.3
OS support
Windows NT 4.0
Size
16.5KB
Filename
Name
Version
1.2
OS support
Windows 2000
Size
31.9KB
Filename
Name
Version
1.08.5
OS support
Windows 2000 Windows 9x Windows XP
Size
11.4MB
Filename
Name
Version
1.008
OS support
Empty
Size
2.2MB
Filename
Name
Version
1.0
OS support
Windows 9x
Size
406.4KB
Filename
image1 Image 1 of 3 (Karbist)
image2 Image 2 of 3 (Karbist)
image3 Image 3 of 3 (Karbist)
