EPoX/ProNiX EP-8KMM3I
Chipset
Socket
FSB speeds 200MHz266MHz333MHz
Form factorMicroATX (max 244 x 244 mm)
Dimensions244mm x 220mm
Max VRAM size32MB
Cache
None/Integrated in the CPU
Max RAM size
2GB
RAM type DDR UDIMM
PSU connector
Multi CPU supportno
I/O ports1x
Floppy interface
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
1x
S/PDIF
1x
Serial
6x
USB 2.0
1x
VGA
Expansion slots1x
1.5V AGP
3x
32-bit PCI
Notes
Uses optional VT6103 Ethernet controller.
Last updated 2025-03-13T23:26:22Z
Board info score is 9.6/10
Chips
-
Chipset part
-
Audio
CPU family support
3 BIOS files available
Award - 5 entries
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
11/24/2004-KM400-8235-6A6LYPANC-00
Note
Core version
6.00PG
BIOS version
4B24
Logs
POST string
10/04/2004-KM400-8235-6A6LYPANC-00
Note
8km34A04.bin
Core version
6.00PG
BIOS version
Logs
POST string
08/11/2004-KM400-8235-6A6LYPANC-00
Note
8km34811.bin
Core version
6.00PG
BIOS version
Logs
POST string
02/04/2004-KM400-8235-6A6LYPANC-00
Note
8km34204.bin
Core version
6.00PG
BIOS version
Logs
POST string
08/28/2003-KM400-8235-6A6LYPANC-00
Note
Core version
6.00PG
BIOS version
3828
Logs
8 drivers available
Name
Version
OS support
Size
Filename
Name
Version
V3.00a
OS support
MS-DOS
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP
Size
1.9MB
Filename
Name
Version
5.70d
OS support
Windows 2000
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Windows XP
Size
3.9MB
Filename
Name
Version
5.24A
OS support
Windows 2000
Windows 9x
Windows XP
Size
12.7MB
Filename
Name
Version
5.24A
OS support
Windows 2000
Windows 9x
Windows XP
Size
12.7MB
Filename
Name
Version
4.56V
OS support
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP
Size
1.4MB
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Image 1 of 4
Image 2 of 4
Image 3 of 4 (Kopeć/kopeckop)
Image 4 of 4 (Kopeć/kopeckop)
