ECS L7VMM2 (PCB 1.1)
chipChipset
cpuSocket
Socket A (PGA462)
speedFSB speeds
200MHz266MHz
moboForm factor
MicroATX (max 244 x 244 mm)
dimDimensions
244mm x 230mm
chipCache
None/Integrated in the CPU
ramMax RAM size
2GB
ramRAM type
DDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
connI/O ports
1x
3.5mm Audio Combo
1x
Floppy interface
1x
Gameport
2x
IDE interface
2x
IEEE 1394
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
1x
Serial
6x
USB 2.0
1x
VGA
cardExpansion slots
2x
32-bit PCI
1x
CNR
1x
Universal AGP

Also known as:

Last updated 2023-08-17T17:35:33Z
Board info score is 9.6/10
chipChipset parts
VIA VT8235 VIA VT8375 (KM266)
chipAudio chips
VIA VT1612A (Vinyl 2-Channel AC'97 Codec)
chipVideo chips
S3 86C420 (ProSavage8)
chipNetwork chips
VIA VT6103 (Rhine II Fast Ethernet PHY)
chipSuper I/O chips
ITE IT8705F
chipFireWire ctrl. chips
VIA VT6306 (PCI 1394a IHC)
ramMax VRAM size
32MB
cpuCPU family support
5 files available

Vendor: Award [5 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
05/21/2004-KM266-8235-C-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
11/25/2003-KM266-8235-C-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
08/30/2003-KM266+8235-C-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
06/03/2003-KM266-8235-C-00
Note
Core version
6.00PG
BIOS version
Logs
POST string
05/19/2003-KM266+8235-C-00
Note
Core version
6.00PG
BIOS version
Logs
drv 2 known good drivers available
Name
Version
OS support
Size
Filename
Name
Version
4.1
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP
Size
6.9MB
Filename
Name
Version
4.43V
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP
Size
1.1MB
Filename
Name
Version
OS support
Size
Filename
Name
Version
5.70d
OS support
Windows 2000 Windows 9x Windows NT 3.5x Windows NT 4.0 Windows XP
Size
3.9MB
Filename
Name
Version
13.01.09
OS support
Windows 9x
Size
5.4MB
Filename
Name
Version
1.3
OS support
Windows 9x
Size
19KB
Filename
Name
Version
1.3
OS support
Windows NT 4.0
Size
16.5KB
Filename
Name
Version
1.2
OS support
Windows 2000
Size
31.9KB
Filename
Name
Version
3.32
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows Vista Windows XP
Size
4.1MB
Filename
Name
Version
4.3
OS support
MS-DOS Windows 2000 Windows 3.1x Windows 9x Windows NT 3.5x Windows NT 4.0 Windows XP
Size
6.2MB
Filename
Name
Version
13.01.09
OS support
Windows 9x
Size
5.4MB
Filename
doc 2 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
