ECS H81H3-M4 V1.0

Chipset

Intel H81 (Lynx Point)

Socket

Socket H3 (LGA1150)

FSB speed

Empty

Form factor

Mini DTX (max 203 × 170 mm)

Dimensions

190 x 170mm

Cache

None/Integrated in the CPU

Max RAM size

16GB

RAM type

DDR3 UDIMM

PSU connector

ATX 2.x (24-pin ATX) ATX P4 connector 12v (4-pin P4)

Also known as

Acer H81H3-M4 V1.0
Acer Veriton M200-H81 system board (some models)
ECS H81H3-M4V (common typo)

I/O ports

3.5mm Audio Combo

HDMI

PS/2 keyboard

PS/2 mouse

RJ-45 LAN

SATA II

SATA III

USB 2.0

USB 3.0

VGA

Expansion slots

PCIe x1

PCIe x16

Notes

NOTE: The latest ECS BIOS can only be flashed through a BIOS update for an already functional system, as it is not a complete ROM. If your BIOS is bricked and you need to recover it, please flash one of the 8 MB BIOS dumps instead. You can then update to the latest version once the system is functional.

Can have either VIA VT1705 or Realtek ALC662 audio chip.
Acer OEM version was used in some Veriton M200-H81 series PCs and it can be updated to retail ECS BIOS, although it is unknown which specific models of this series have this board. Check CPU-Z/HWiNFO or inside the chassis to determine your motherboard model.

Last updated 2024-12-13T12:04:20Z

Board info score is 7.4/10

Chips
