DataExpert MGX7510
Chipset
Socket
FSB speeds 30MHz33MHz
Form factorBaby AT (max 220 x 330 mm)
Dimensions220 mm x 220 mm
Max VRAM size4MB
Cache
None/Integrated in the CPU
Max RAM size
128MB
RAM types 72-pin FPM72-pin EDOSDR UDIMM
PSU connector
Multi CPU supportno
Also known as
- GCT MGX
I/O ports1x
AT Keyboard
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
PS/2 mouse
1x
Parallel
2x
Serial
1x
TV-Out
1x
VGA
Expansion slots2x
16-bit ISA
3x
32-bit PCI
Last updated 2023-05-29T18:40:46Z
Board info score is 9.8/10
Chips
-
Clock Synth / PLL
-
RAMDAC
-
Super I/O
CPU family support
1 BIOS file available
Award - 1 entry
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
12/09/97-Gx86-Cx5510-2A431D09C-00
Note
Core version
4.51PG
BIOS version
Logs
7 drivers available
Name
Version
OS support
Size
Filename
Name
Version
4.10.01.1305
OS support
Windows 3.1x
Windows NT 4.0
Size
363.2KB
Filename
Name
Version
4.10.00.0152
OS support
MS-DOS
Windows 3.1x
Windows 9x
Windows NT 4.0
Size
27.2MB
Filename
Name
Version
4.10.0.00152
OS support
Windows 9x
Windows NT 4.0
Size
35.9MB
Filename
3 board documents available
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1997-06-23
File
Logs
Image 1 of 6 (Microhouse)
Image 2 of 6 (eesz34)
Image 3 of 6 (eesz34)
Image 4 of 6 (eesz34)
Image 5 of 6 (eesz34)
Image 6 of 6 (AT House)
