Commodore PC-10 III
Logs
chipChipset
cpuSocket
DIP40
speedFSB speed
8MHz
moboForm factor
OEM / Proprietary
dimDimensions
Empty
ramMax VRAM size
256KB
chipCache
None/Integrated in the CPU
ramMax RAM size
Empty
ramRAM type
Empty
pwrPSU connector
OEM/Proprietary
tag Also known as
connI/O ports
1x
AT Keyboard
1x
Floppy interface
1x
Parallel
2x
Serial
1x
VGA
1x
XTA interface
cardExpansion slots
3x
8-bit ISA
wrench Known issues
  • Leaky Ni-Cd clock battery

The Ni-Cd battery may be leaking, risking damage to PCB layers & nearby components. Promptly remove the battery & clean corrosion/alkaline salts from the board. Use white vinegar to dissolve salts, but exercise caution as vinegar can corrode exposed metals. A thorough examination & repair may be needed. Replace battery with guide: https://github.com/wiretap-retro/Not-A-Varta

notes Notes

PC20-III had hard drive and single 360k floppy, PC10-III had dual 360k floppies and no harddrive, PC10-SD had single 720k 3.5"and 360k floppies.

Last updated 2025-02-13T13:11:08Z
Board info score is 8.4/10
bios 9 BIOS files available

vendor Phoenix - 9 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
beta
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
Note
Core version
2.12
BIOS version
Logs
POST string
06/14/88
Note
318085-001 floppy image
Core version
2.12
BIOS version
Logs
drv No drivers available
doc 2 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2009-12
File
Logs
Chip
Release date
2009-12
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
1990
File
Logs
Chip
Release date
1990
File
Logs
doc 6 other files available
Title
File
Logs
Title
Character set ROMs (3 different ones) for U597 (near the graphics chip)
File
Logs
Title
DOS drivers and utilities
File
Logs
Title
MS-DOS 3.21 Colt
File
Logs
Title
System Disk
File
Logs
Title
System utilities disk 1/2
File
Logs
Title
System utilities disk 2/2
File
Logs
image1 Image 1 of 12 (Predator99)
image2 Image 2 of 12 (HanJammer)
image3 Image 3 of 12 (krivulak)
image4 Image 4 of 12 (krivulak)
image5 Image 5 of 12 (krivulak)
image6 Image 6 of 12 (krivulak)
image7 Image 7 of 12 (HanJammer)
image8 Image 8 of 12 (krivulak)
image9 Image 9 of 12 (krivulak)
image10 Image 10 of 12 (krivulak)
image11 Image 11 of 12 (krivulak)
image12 Image 12 of 12 (krivulak)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
