Biostar M6VLB
Logs
chipChipset
cpuSocket
Socket 370 (PGA370)
speedFSB speeds
66MHz100MHz133MHz
moboForm factor
MicroATX (max 244 x 244 mm)
dimDimensions
244mm x 200mm
ramMax VRAM size
8MB
chipCache
None/Integrated in the CPU
ramMax RAM size
1GB
ramRAM type
SDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
connI/O ports
1x
3.5mm Audio Combo
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
2x
Serial
4x
USB 1.x
1x
VGA
cardExpansion slots
1x
16-bit ISA
3x
32-bit PCI
1x
AMR
notes Notes

Optionally uses VT82C686B southbridge, marked by the "ATA 100" sticker. There is nothing known about a separate model name for those.

Last updated 2024-06-30T21:17:09Z
Board info score is 9.4/10
bios 3 BIOS files available

vendor Award - 3 entries

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
08/20/2001-601-686B-6A6LIB09C-00
Note
No logo
Core version
6.00PG
BIOS version
Logs
POST string
08/20/2001-601-686B-6A6LIB09C-00
Note
Logo
Core version
6.00PG
BIOS version
Logs
POST string
03/26/2001-601-686A-6A6LIB09C-00
Note
No logo
Core version
6.00PG
BIOS version
Logs
drv 14 drivers available
Name
Version
OS support
Size
Filename
Name
Version
A4.06
OS support
Windows 2000 Windows 9x Windows XP
Size
17.9MB
Filename
Name
Version
A2.53
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP
Size
14.5MB
Filename
Name
Version
4.43V
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP
Size
1.1MB
Filename
Name
Version
Empty
OS support
MS-DOS
Size
227.7KB
Filename
Name
Version
5.70d
OS support
Windows 2000 Windows 9x Windows NT 3.5x Windows NT 4.0 Windows XP
Size
3.9MB
Filename
Name
Version
V3.00a
OS support
MS-DOS Windows 2000 Windows 9x Windows NT 4.0 Windows XP
Size
1.9MB
Filename
Name
Version
2.20a
OS support
MS-DOS OS/2 Warp 4.x Windows 9x Windows NT 4.0 Windows XP
Size
4.3MB
Filename
Name
Version
2.10c
OS support
MS-DOS OS/2 Warp 4.x Windows 2000 Windows 9x Windows NT 3.5x Windows NT 4.0 Windows XP
Size
4.3MB
Filename
Name
Version
13.01.03
OS support
Windows 9x
Size
5.2MB
Filename
Name
Version
10.10.20
OS support
Windows NT 4.0
Size
3.7MB
Filename
Name
Version
4.13.01.3124
OS support
Windows 9x
Size
4.9MB
Filename
Name
Version
4.11.01.2182
OS support
Windows 9x
Size
3.3MB
Filename
Name
Version
4.03.00.3120
OS support
Windows NT 4.0
Size
8.2MB
Filename
Name
Version
1.08
OS support
Windows 2000 Windows 9x
Size
553.6KB
Filename
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
2002-02
File
Logs
Family
Release date
2000-02
File
Logs
Family
Release date
2001-06
File
Logs
Socket
Release date
File
Logs
Socket
Release date
1997-05
File
Logs
Socket
Release date
File
Logs
Socket
Release date
1999-04
File
Logs
Socket
Release date
1999-12
File
Logs
Socket
Release date
2000-07
File
Logs
image1 Image 1 of 2 (evasive)
image2 Image 2 of 2 (TheRealZago)

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
