ASUS Rampage III Black Edition
chipChipset
cpuSocket
Socket B (LGA1366)
speedFSB speeds
2400MHz3200MHz
moboForm factor
Extended ATX/EATX (max 305 × 330 mm)
dimDimensions
305mm x 269mm
chipCache
None/Integrated in the CPU
ramMax RAM size
48GB
ramRAM type
DDR3 UDIMM
pwrPSU connector
12V EPS Connector (8-pin EPS) Molex (4-pin) ATX 2.x (24-pin ATX)
connI/O ports
1x
3.5mm Audio Combo
1x
PS/2 KB+MS Combo
1x
RJ-45 LAN
6x
SATA II
2x
SATA III
11x
USB 2.0
4x
USB 3.0
2x
eSATA II
cardExpansion slots
2x
PCIe x1
4x
PCIe x16

Notes:

PCIe supports either x16/x16/x16, x16/x8/x8 or x8/x8/x8/x8 modes

Last updated 2023-06-30T01:39:10Z
Board info score is 9.6/10
3 files available

Vendor: AMI [3 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
65-0602-000001-00101111-092111-TYLERSBUR-A1790000
Note
Core version
080015
BIOS version
Logs
POST string
65-0505-000001-00101111-080411-TYLERSBUR-A1790000
Note
Core version
080015
BIOS version
Logs
POST string
65-0404-000001-00101111-030211-TYLERSBUR-A1790000
Note
Core version
080015
BIOS version
Logs
drv 2 drivers available
Name
Version
OS support
Size
Filename
Name
Version
9.1.2.1007
OS support
Windows 2000 Windows 7 Windows Vista Windows XP
Size
2.4MB
Filename
Name
Version
R2.74
OS support
Windows 2000 Windows 7 Windows Vista Windows XP
Size
30.7MB
Filename
