ASUS CUSI-M
chipChipset
cpuSocket
Socket 370 (PGA370)
speedFSB speeds
66MHz100MHz133MHz
moboForm factor
MicroATX (max 244 x 244 mm)
dimDimensions
229mm x 190mm
chipCache
None/Integrated in the CPU
ramMax RAM size
512MB
ramRAM type
SDR UDIMM
pwrPSU connector
ATX 1.x (20-pin ATX)
connI/O ports
1x
Floppy interface
1x
Gameport
2x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
Parallel
1x
RJ-45 LAN
2x
Serial
4x
USB 1.x
1x
VGA
cardExpansion slots
3x
32-bit PCI
1x
AMR

Also known as:

Last updated 2024-08-01T16:49:17Z
Board info score is 9.4/10
19 files available

Vendor: Award [19 entries]

POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
07/30/2003-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
07/30/2003-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
02/13/2003-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
02/13/2003-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
10/22/2002-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
10/22/2002-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
09/30/2002-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
09/30/2002-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
09/18/2002-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
09/18/2002-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
04/29/2002-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
04/29/2002-SiS630E-CUSI-MN
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
06/07/2001-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
06/07/2001-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
02/23/2001-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
02/23/2001-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
01/09/2001-SiS630E-CUSI-MN
Note
no LAN
Core version
Asus v6.0
BIOS version
Logs
POST string
12/11/2000-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
POST string
11/15/2000-SiS630E-CUSI-M
Note
Core version
Asus v6.0
BIOS version
Logs
drv 10 drivers available
Name
Version
OS support
Size
Filename
Name
Version
Empty
OS support
Windows 2000 Windows 9x Windows NT 4.0
Size
1.8MB
Filename
Name
Version
1.98
OS support
MS-DOS
Size
64.9KB
Filename
Name
Version
4.06.1096
OS support
Windows 9x
Size
1.8MB
Filename
Name
Version
5.12.01.0639
OS support
Windows 9x
Size
3.1MB
Filename
Name
Version
4.01.0230
OS support
Empty
Size
156KB
Filename
Name
Version
5.12.01.0639
OS support
Windows 2000
Size
3.1MB
Filename
Name
Version
5.12.01.0639
OS support
Windows XP
Size
3.1MB
Filename
Name
Version
1.3
OS support
Windows 9x
Size
19KB
Filename
Name
Version
1.3
OS support
Windows NT 4.0
Size
16.5KB
Filename
Name
Version
1.2
OS support
Windows 2000
Size
31.9KB
Filename
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
File
Logs
Socket
Release date
File
Logs
Socket
Release date
File
Logs
Socket
Release date
File
Logs
Socket
Release date
File
Logs
Socket
Release date
File
Logs
Socket
Release date
File
Logs

Disclaimer

The info found in this page might not be entirely correct. Check out this guide to learn how you can improve it.
