ASRock P45TurboTwins2000
Chipset
Socket
FSB speeds 800MHz1066MHz1333MHz1600MHz2000MHz
Form factorATX (max 305 x 244 mm)
Dimensions305mm x 244mm
Cache
None/Integrated in the CPU
Max RAM size
8GB(DDR3-1333 / DDR2-1066)
RAM types DDR3 UDIMMDDR2 UDIMM
PSU connector
I/O ports1x
3.5mm Audio Combo
1x
Floppy interface
1x
IDE interface
1x
PS/2 keyboard
1x
PS/2 mouse
1x
RJ-45 LAN
1x
S/PDIF
6x
SATA II
1x
Serial
1x
Toslink
12x
USB 2.0
2x
eSATA II
Expansion slots3x
32-bit PCI
2x
PCIe x1
1x
PCIe x16
1x
PCIe x16 @ x8
Notes
-
Supports ATi CrossFire.
-
2000MHz FSB as o/c option.
-
eSATA connectors are rerouted SATA connectors.
Last updated 2024-01-08T00:19:23Z
Board info score is 9.6/10
Chips
-
Chipset part
CPU family support
9 BIOS files available
AMI - 9 entries
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
64-203-0000010-00101111-020509-INTEL-AS129203
Note
Core version
080015
BIOS version
Logs
POST string
64-191-0000010-00101111-112508-INTEL-AS129191
Note
Core version
080015
BIOS version
Logs
POST string
64-171-0000010-00101111-102708-INTEL-AS129171
Note
Core version
080015
BIOS version
Logs
POST string
64-162-0000010-00101111-090108-INTEL-AS129162
Note
Core version
080015
BIOS version
Logs
POST string
64-151-0000010-00101111-081408-INTEL-AS129151
Note
Core version
080015
BIOS version
Logs
POST string
64-132-0000010-00101111-072908-INTEL-AS129132
Note
Core version
080015
BIOS version
Logs
POST string
64-127-0000010-00101111-071808-INTEL-AS129127
Note
Core version
080015
BIOS version
Logs
POST string
64-114-0000010-00101111-062608-INTEL-AS129114
Note
Core version
080015
BIOS version
Logs
POST string
64-101-0000010-00101111-060208-INTEL-AS129101
Note
Core version
080015
BIOS version
Logs
2 drivers available
Name
Version
OS support
Size
Filename
Name
Version
R2.74
OS support
Windows 2000
Windows 7
Windows Vista
Windows XP
Size
30.7MB
Filename
1 board document available
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2006-04-25
File
Logs
Chip
Release date
2008-04-07
File
Logs
Chip
Release date
2010-07
File
Logs
Chip
Release date
2008-09
File
Logs
Chip
Release date
2008-10
File
Logs
Chip
Release date
2013-09
File
Logs
Chip
Release date
2008-07
File
Logs
Family
Release date
File
Logs
Family
Release date
2008-01
File
Logs
Family
Release date
2008-01
File
Logs
Family
Release date
2008-10
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2008-12
File
Logs
Family
Release date
2009-01
File
Logs
Family
Release date
2011-09-06
File
Logs
Family
Release date
2011-09-06
File
Logs
Family
Release date
2011-09-06
File
Logs
Family
Release date
2011-09-06
File
Logs
Family
Release date
2008-12
File
Logs
Family
Release date
2007-06
File
Logs
Family
Release date
2007-10-30
File
Logs
Family
Release date
2007-10-30
File
Logs
Family
Release date
2011-09-08
File
Logs
Family
Release date
2011-09-08
File
Logs
Family
Release date
2007-08
File
Logs
Family
Release date
2007-08
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2007-04
File
Logs
Family
Release date
2007-04
File
Logs
Family
Release date
2009-08
File
Logs
Family
Release date
2009-08
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2007-10
File
Logs
Family
Release date
2010-12
File
Logs
Family
Release date
2009-08
File
Logs
Family
Release date
2009-08
File
Logs
Family
Release date
2007-11-08
File
Logs
Family
Release date
2007-11-08
File
Logs
Family
Release date
2011-09-08
File
Logs
Family
Release date
2011-09-08
File
Logs
Family
Release date
2011-09-08
File
Logs
Family
Release date
File
Logs
Socket
Release date
File
Logs
Image 1 of 3 (ASRock)
Image 2 of 3 (ASRock)
Image 3 of 3 (ASRock)
