Ampro Little Board/386SX II
Logs
chipChipset
cpuSocket
PQFP100
speedFSB speed
25MHz
moboForm factor
EBX/Little Board/Biscuit SBC 5.25" (max 203 x 146 mm)
dimDimensions
203mm x 146mm
chipCache
None/Integrated in the CPU
ramMax RAM size
16MB
ramRAM type
30-pin SIMM
pwrPSU connector
Molex (4-pin)
maxcpuMulti CPU support
no
tag Also known as
  • Ampro Little Board/386SX-IIA
connI/O ports
1x
Floppy interface
1x
IDE interface
1x
Internal SCSI
1x
PS/2 keyboard
1x
Parallel
2x
Serial
cardExpansion slots
1x
16-bit ISA
1x
8-bit ISA
wrench Known issues
  • Leaky Ni-Cd clock battery

The Ni-Cd battery may be leaking, risking damage to PCB layers & nearby components. Promptly remove the battery & clean corrosion/alkaline salts from the board. Use white vinegar to dissolve salts, but exercise caution as vinegar can corrode exposed metals. A thorough examination & repair may be needed. Replace battery with guide: https://github.com/wiretap-retro/Not-A-Varta

Last updated 2023-08-21T15:56:49Z
Board info score is 7.4/10
chip Chips
cpufam CPU family support
bios 0 BIOS files available
drv No drivers available
doc 2 board documents available
Release date
File
Logs
Release date
File
Logs
Release date
File
Logs
image1 Image 1 of 2 (evasive)
image2 Image 2 of 2
