ADLink ReadyBoard 740
Chipset
Socket
FSB speed 400MHz
Form factorEPIC (max 115 x 165 mm)
Dimensions115mm x 165mm
Cache
None/Integrated in the CPU
Max RAM size
2GB
RAM type 200-pin DDR2 SO-DIMM
PSU connector
Also known as
I/O ports1x
DVI
1x
GPIO
1x
LVDS
1x
PS/2 KB+MS Combo
1x
RJ-45 LAN
2x
SATA II
4x
Serial
6x
USB 2.0
1x
VGA
Expansion slots1x
Mini-PCIe
Notes
4GB optional onboard SSD
PCI-104 connector
RB-740-R-14 (Atom D410 1.66 GHz, Integrated Graphics, 24-bit LVDS, 4GB on board SSD)
RB-740-R-16 (Atom D510 1.66 GHz, H.264 decoder, DVI, 24-bit LVDS, 4GB on board SSD)
RB-740-R-17 (Atom N450 1.66 GHz, H.264 decoder, DVI, 24-bit LVDS, 4GB on board SSD)
RB-740-R-18 (Atom N450 1.66 GHz, Integrated Graphics, 18-bit LVDS, 4GB on board SSD)
RB-740-R-19 (Atom D510 1.66 GHz, DVI, 24-bit LVDS, 4GB on board SSD)
Last updated 2024-09-04T00:04:10Z
Board info score is 9.6/10
Chips
CPU family support
1 BIOS file available
AMI - 1 entry
POST string
Note
Core Ver.
BIOS Ver.
Logs
POST string
65-0100-009999-00101111-011311-Pineview-RB740A14
Note
Core version
080016
BIOS version
Logs
2 drivers available
Name
Version
OS support
Size
Filename
Name
Version
V3.4
OS support
Empty
Size
8MB
Filename
Name
Version
R2.74
OS support
Windows 2000
Windows 7
Windows Vista
Windows XP
Size
30.7MB
Filename
3 board documents available
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
2008-04-15
File
Logs
Chip
Release date
2005-08-25
File
Logs
Family
Release date
File
Logs
Family
Release date
2011-09-14
File
Logs
Family
Release date
2011-09-14
File
Logs
Family
Release date
2011-09-15
File
Logs
Family
Release date
2011-09-15
File
Logs
Family
Release date
2010-06
File
Logs
Family
Release date
2010-06
File
Logs
Family
Release date
2010-03
File
Logs
Family
Release date
2010-03
File
Logs
Family
Release date
2009-12
File
Logs
Image 1 of 4
Image 2 of 4
Image 3 of 4
Image 4 of 4
